ls -l | grep "chan"

type hchan struct{
   qcount uint 		// 表示当前队列中的剩余元素
   dataqsiz uint		// 表示循环队列的大小，即可以存放元素的个数
   buf unsafe.Pointer	// 指向一个dataqsiz大小的数组，也就是环形队列的指针
   elemsize uint16		// 每个元素的大小
   closed uint32		// 标记关闭状态
   elemtype *_type		// 元素类型
   sendx uint			// 队列下标，指元素写入时存放到队列中的位置
   recvx uint			// 队列下标，指元素从队列的该位置读出
   recvq waitq			// 等待读消息的goroutine队列
   sendq waitq			// 等待写消息的goroutine队列
   lcok  mutex			// 互斥锁，chan不允许并发读写
}

type waitq struct {
	first *sudog
	last  *sudog
}

type sudog struct {
	// The following fields are protected by the hchan.lock of the
	// channel this sudog is blocking on. shrinkstack depends on
	// this for sudogs involved in channel ops.

	g *g

	next *sudog
	prev *sudog
	elem unsafe.Pointer // data element (may point to stack)

	// The following fields are never accessed concurrently.
	// For channels, waitlink is only accessed by g.
	// For semaphores, all fields (including the ones above)
	// are only accessed when holding a semaRoot lock.

	acquiretime int64

	releasetime int64
	ticket      uint32

	// isSelect indicates g is participating in a select, so
	// g.selectDone must be CAS'd to win the wake-up race.
	isSelect bool

	// success indicates whether communication over channel c
	// succeeded. It is true if the goroutine was awoken because a
	// value was delivered over channel c, and false if awoken
	// because c was closed.
	success bool

	parent   *sudog // semaRoot binary tree
	waitlink *sudog // g.waiting list or semaRoot
	waittail *sudog // semaRoot
	c        *hchan // channel
}

// sudog is necessary because the g ↔ synchronization object relation
// is many-to-many. A g can be on many wait lists, so there may be
// many sudogs for one g; and many gs may be waiting on the same
// synchronization object, so there may be many sudogs for one object.

func chansend(c *hchan, ep unsafe.Pointer, block bool, callerpc uintptr) bool {
	if c == nil {
		if !block {
			return false
		}
		gopark(nil, nil, waitReasonChanSendNilChan, traceEvGoStop, 2)
		throw("unreachable")
	}

	if debugChan {
		print("chansend: chan=", c, "\n")
	}

	if raceenabled {
		racereadpc(c.raceaddr(), callerpc, abi.FuncPCABIInternal(chansend))
	}

	// Fast path: check for failed non-blocking operation without acquiring the lock.
	//
	// After observing that the channel is not closed, we observe that the channel is
	// not ready for sending. Each of these observations is a single word-sized read
	// (first c.closed and second full()).
	// Because a closed channel cannot transition from 'ready for sending' to
	// 'not ready for sending', even if the channel is closed between the two observations,
	// they imply a moment between the two when the channel was both not yet closed
	// and not ready for sending. We behave as if we observed the channel at that moment,
	// and report that the send cannot proceed.
	//
	// It is okay if the reads are reordered here: if we observe that the channel is not
	// ready for sending and then observe that it is not closed, that implies that the
	// channel wasn't closed during the first observation. However, nothing here
	// guarantees forward progress. We rely on the side effects of lock release in
	// chanrecv() and closechan() to update this thread's view of c.closed and full().
	if !block && c.closed == 0 && full(c) {
		return false
	}

	var t0 int64
	if blockprofilerate > 0 {
		t0 = cputicks()
	}

	lock(&c.lock)

	if c.closed != 0 {
		unlock(&c.lock)
		panic(plainError("send on closed channel"))
	}

	if sg := c.recvq.dequeue(); sg != nil {
		// Found a waiting receiver. We pass the value we want to send
		// directly to the receiver, bypassing the channel buffer (if any).
		send(c, sg, ep, func() { unlock(&c.lock) }, 3)
		return true
	}

	if c.qcount < c.dataqsiz {
		// Space is available in the channel buffer. Enqueue the element to send.
		qp := chanbuf(c, c.sendx)
		if raceenabled {
			racenotify(c, c.sendx, nil)
		}
		typedmemmove(c.elemtype, qp, ep)
		c.sendx++
		if c.sendx == c.dataqsiz {
			c.sendx = 0
		}
		c.qcount++
		unlock(&c.lock)
		return true
	}

	if !block {
		unlock(&c.lock)
		return false
	}

	// Block on the channel. Some receiver will complete our operation for us.
	gp := getg()
	mysg := acquireSudog()
	mysg.releasetime = 0
	if t0 != 0 {
		mysg.releasetime = -1
	}
	// No stack splits between assigning elem and enqueuing mysg
	// on gp.waiting where copystack can find it.
	mysg.elem = ep
	mysg.waitlink = nil
	mysg.g = gp
	mysg.isSelect = false
	mysg.c = c
	gp.waiting = mysg
	gp.param = nil
	c.sendq.enqueue(mysg)
	// Signal to anyone trying to shrink our stack that we're about
	// to park on a channel. The window between when this G's status
	// changes and when we set gp.activeStackChans is not safe for
	// stack shrinking.
	gp.parkingOnChan.Store(true)
	gopark(chanparkcommit, unsafe.Pointer(&c.lock), waitReasonChanSend, traceEvGoBlockSend, 2)
	// Ensure the value being sent is kept alive until the
	// receiver copies it out. The sudog has a pointer to the
	// stack object, but sudogs aren't considered as roots of the
	// stack tracer.
	KeepAlive(ep)

	// someone woke us up.
	if mysg != gp.waiting {
		throw("G waiting list is corrupted")
	}
	gp.waiting = nil
	gp.activeStackChans = false
	closed := !mysg.success
	gp.param = nil
	if mysg.releasetime > 0 {
		blockevent(mysg.releasetime-t0, 2)
	}
	mysg.c = nil
	releaseSudog(mysg)
	if closed {
		if c.closed == 0 {
			throw("chansend: spurious wakeup")
		}
		panic(plainError("send on closed channel"))
	}
	return true
}
